HR 880 | |
Capacity | 880 Bushels |
Struck Level ASAE S324.1 | 712 cu. ft. |
Heaped ASAE S324.1 | 1096 cu. Ft. |
Load carrying capacity | 24.2 tons |
Loading height | 98 in. |
Inside width of box | 60 in. to 96 in. |
Depth of box | 53.2 in. |
Overall width w/ truck tires (tire size) | |
Overall width w/flotation tires (tire size) | 132 in. (700/40-22.5) |
Top of moving panel | |
Top of beaters | 135 in. |
Overall length | 32 ft. |
Face of moving panel to beater centerline | |
Number of beaters | 2 |
Beater speed | 420 rpm. |
Fan diameter | 34.6 in. |
Number of paddles on beaters | 70 total |
Tractor PTO HP (min. recommended) | 200 hp |
Number of unloading speeds | Infinite from 0-15.21 ft./min. |
PTO speed | 1000 RPM |
PTO shaft diameter | 1 ¾ in. |
Number of end gate cylinders | 2 |
Tare weight | 17,040 lbs. |
