| | HR 250 |
 |
| Capacity | 250 Bushels |
| Struck Level ASAE S324.1 | 147 cu. ft. |
| Heaped ASAE S324.1 | 249 cu. ft. |
| Load carrying capacity | 6.5 tons |
| Loading height | 54.5 in. |
| Inside width of box | 61.75 |
| Depth of box | 28.5 |
| Overall width w/ truck tires (tire size) | 104.5 in. (11 R22.5) |
| Overall width w/flotation tires (tire size) | 109.5 in. (16.5L-16.1) |
| Top of moving panel | 66.5 in. |
| Top of beaters | 76 in. |
| Overall length | 23 ft. |
| Face of moving panel to beater centerline | 13 ft. 10 in. |
| Number of beaters | Two |
| Beater speed | 350 RPM |
| Fan diameter | 29.7 in. |
| Number of paddles on beaters | 36 |
| Tractor PTO HP (min. recommended) | 60 HP |
| Number of unloading speeds | Infinite from 0-16 ft./min. |
| PTO speed | 540 |
| PTO shaft diameter | 1-3/8 in. |
| Number of end gate cylinders | One |
| Tare weight | 5,540 lbs. |
